PetMAP™ g3
Monitoring - Diagnostic
PetMAP™ g3
petMAP™, Unique Patented Technology!
petMAP™ family: More than 15 years of trusted clinical partnership with small animal veterinary professionals worldwide!
petMAP™: A valuable Tool for Vital Signs Measurement & Monitoring in Veterinary Medicine
- Portable, goes anywhere
- Good Accuracy. Sensitive to small signals produced by small animals
- Improved artifact handling over other oscillometric devices
- Species (cat/dog) and cuff site (forearm, tail, hind foot) specific for best accuracy/correlation to IAP
- Durable cuffs. 12 sizes from 2.0 – 13.0cm
- Faster readings…less stress for the patient
- EASY TO USE….
Easy and reliable:
- Rechargeable batteries
- Larger 5'' (12.7 cm) display
- Monitoring mode
- Temperature (probe sold separately)
And still:
- Proven petMAP technology with PPO (petMAP Proprietary Optimizations)
- Display of systolic, diastolic, mean arterial pressure (MAP) along with heart rate
- Easy to use "no menu" touch screen display
- Real-time display of oscillometric "envelope"
- Correlation to intra-arterial readings
- Tabular display of readings and NSV in clinic
- Optional pole or table mount
- A SD card slot allows to record all monitored and measured patient vital signs on a user supplied SD card
Compare its features and benefits in the chart below:
PetMAPg3™ continuously uses Dual Oscillation Channel Analysis during each determination. High and low gain channels are analyzed simultaneously BP measurement reliability and sensitivity are enhanced across the broadest range of patient sizes. Feature requires no user setting or adjustment.
PetMAPg3™ has PPO (petMAP Proprietary Optimization), allowing the user to specify the species (cat, dog) and measurement site (forearm, tail, hind foot).
PPO improves the correlation to IntraArterial Pressures (IAP), the patient’s true blood
pressure.
PetMPg3™ calculates and automatically displays the NSV (Nominal Session Value) after each reading during a session.
NSV is a much more robust calculation than a simple average. NSV is most representative
ot the patient BP during a session, and is typically the charted value.
PetMAPg3™ displays the cuff pressure and the oscillation amplitude during a determination.The user has the ability to visually assess the quality of each reading and to end the determination if appropriate. Severe motion artifact is visualized during the reading.
PetMAPg3™ can display the last ten readings as both a tabular list as well as a graphical chart; values are “aged” from the time of power-up.
Individual determinations are available for charting. The user can view the graph and easily see if the values are consistent and if the session can be terminated.
PetMAPg3™ is compact, handheld and battery operated.
Convenient for exam room use (hypertension screening), but also for trauma, anesthesia, procedures and even house calls.
PetMAPg3™ includes seven cuffs of various sizes from 2 to 5.5 cm.
The proper cuff size is critical to accurate BP measurement. PetMAP provides the broadest cuff size range available.
PetMAPg3™ is specifically developed for blood pressure measurement on cats and dogs.
PetMAPg3™ provides systolic, diastolic, mean arterial pressure, and heart rate using a propriety new oscillometric technology for enhanced sensitivity, accuracy, and performance.
PetMAPg3™ is based on intra-arterial measurements.
Integrated graphic display provides
- Digital display of systolic, diastolic, MAP and heart rate
- Real-time display of the oscillometric “envelope”
- Tabular list of measurement session values
- Graphical trend of session values
- Real-time calculation and display of the NSV
| petMAP graphic II | petMAP g3 | petMAP+ II | petMAP+ II SpO2 | |
|---|---|---|---|---|
| Measured parameters |
|
|
|
|
| Display | Color LCD, Touchscreen 4.3'' | Color LCD, Touchscreen 5'' | Color LCD, Touchscreen 5'' | Color LCD, Touchscreen 5'' |
| Data storage/Transfer connectivity | SD card (not provided) | SD card / Mini USB (both not provided) | ||
| Power | 4 AA Alakaline | 4 AA NiMH and AC/DC Adapter | ||
| Gonflage des brassards | Automatique | Automatique et programmable en mode monitoring | ||
| NIBP features | PPO (petMAP proprietary optimizations - species & cuff site settings) - NSV (Nominal Session Value) | |||
| Included accessories |
|
|
|
|
| Optional accessories |
|
|
|
|
| Dimensions and weight | 15 x 8 x 3 cm - 400 gr | |||
Do not hesitate to send us your comments to share your experience
PetMAP™ g3 in video
